The Infranet

Artificial intelligence depends on large-scale datasets for both training and inference. However, much of this data cannot be freely moved or centralized—it is bound by regulatory requirements, organizational policies, or jurisdictional constraints. This raises a fundamental question: how do we enable large-scale AI computation while preserving data sovereignty?

Current Internet infrastructure is dominated by centralized computing architectures. In these models, data flows to remote data centers, requiring users and organizations to relinquish control of their data to third-party providers. This fundamentally violates data sovereignty—the ability to maintain ownership, governance, and control over data within legal and organizational boundaries.

Alternatively, decentralized computing architectures distribute workloads across autonomous nodes without central coordination. However, this approach requires data replication across nodes to ensure availability and consensus, equally compromising data sovereignty. Organizations cannot guarantee where their data resides, who accesses it, or how it propagates through the network. Both centralized and decentralized models require data to move to compute, making them unsuitable to maintain data sovereignty.

To preserve data sovereignty while enabling large-scale AI computation, we must invert the traditional paradigm: instead of moving data to compute, we must bring compute to data. This requires a federated computing architecture—one that allows computation to occur across distributed, sovereign data sources without compromising control, locality, or compliance. Achieving this at scale demands seamless interoperability between diverse infrastructures, each governed by its own policies and constraints.

To enable such coordination, we propose the development of Infrastructure Internetworking standards. These standards will define how heterogeneous systems interact securely and efficiently across organizational and jurisdictional boundaries. They will form the backbone of a new digital infrastructure—an evolution of the Internet itself—capable of supporting federated AI at global scale. We call this emerging paradigm the Infranet.

Mission Statement

Our mission is to build the digital infrastructure for the Intelligence Age.

Microstacks

Stack Management System
        map        mountimport

routers/components/services

     domain
                  namespace
                             addrspace

Microstacks is a stack management system designed on the Unix philosophy of composition. It virtualizes network addresses to represent a distributed application as a hierarchy of dependencies, thereby eliminating the need for YAML configuration to define service relationships. Virtual addressing keeps application topology stable while the runtime is deployed and scaled across clouds. These capabilities, called federated deployment and vector scaling, establish a new paradigm for stack management.

Swipe sideways to compare columns

Frameworks

Multics WayParadigm

MonolithicArchitecture

StaticStructure

CentralizedDeployment

VerticalScaling

Microstacks

Unix Philosophy Paradigm

ModularArchitecture

HierarchicalStructure

FederatedDeployment

VectorScaling

Orchestrators

GNU ManifestoParadigm

MicroserviceArchitecture

DynamicStructure

DistributedDeployment

HorizontalScaling

Hierarchical Structure

A stack is an application organized as paths instead of loose service names. Use map to place a GitHub project at a domain, mount to attach frontend dependencies such as an API endpoint, import to bring services into the root, and link to connect those services to the blocks that need them.

stack map · stack mount · stack import · stack link
# Map a GitHub project to a public domain
$ stack map github.com/acme/frontend example.com
Mapped github.com/acme/frontend at example.com

# Mount the frontend API dependency under the domain
$ stack mount myorg/api:1.4 example.com/api
Mounted /api

# Import shared services under the stack root
$ stack import mysql:8 example.com/mysql
Imported /mysql
$ stack import redis:7 example.com/redis
Imported /redis

# Link services into the API address space
$ stack link example.com/mysql example.com/api/mysql
Linked /api/mysql to /mysql
$ stack link example.com/redis example.com/api/redis
Linked /api/redis to /redis

# Inspect the live tree
$ stack ls -r example.com
TYPE       PATH                    IMAGE              VECTORS  PORTS
stack      example.com             github/acme/front  —        443/tcp
component  example.com/api         myorg/api:1.4      —        8080/tcp
service    example.com/mysql       mysql:8            —        3306/tcp
service    example.com/redis       redis:7            —        6379/tcp
link       example.com/api/mysql   example.com/mysql  —        —
link       example.com/api/redis   example.com/redis  —        —

Vector Scaling

Vector scaling is the same operation from another node. SSH into a second cloud, run the same recursive snap, and Microstacks adds another runtime vector without changing the authored stack.

ssh · stack snap
# Open the Azure node console
$ ssh ops@azure-eastus.internal
Connected to azure-eastus.internal

# Run the same command to add a second vector
azure$ stack snap -r example.com
Snapped example.com on azure-eastus.internal

Federated Deployment

Federated deployment does not require a new control system for every environment. SSH into a cloud node, run the same snap command, and the complete stack materializes from the shared model on that node.

ssh · stack snap
# Open the AWS node console
$ ssh ops@aws-use1.internal
Connected to aws-use1.internal

# Snap the complete stack onto AWS
aws$ stack snap -r example.com
Snapped example.com on aws-use1.internal

WordPress

A complete WordPress stack mapped to wordpress.microstacks.com. Map Caddy as the router, mount WordPress at the root path, import MySQL, and snap the full stack into a local deployment.

wordpress.microstacks
# Map Caddy as the router for the WordPress domain
$ stack map \
  caddy:2 wordpress.microstacks.com \
  -- caddy reverse-proxy --from :80 --to http://127.0.0.1:80

# Mount WordPress at the root path
$ stack mount \
  --env=WORDPRESS_DB_HOST=127.0.0.1:3306 \
  --env=WORDPRESS_DB_USER=root \
  --env=WORDPRESS_DB_PASSWORD=wordpress \
  wordpress:7.0.2 wordpress.microstacks.com/

# Import MySQL under /mysql
$ stack import \
  --env=MYSQL_DATABASE=wordpress \
  --env=MYSQL_ROOT_PASSWORD=wordpress \
  mysql:9.7.1 wordpress.microstacks.com/mysql

# Snap the entire stack into a running local deployment
$ stack snap -r wordpress.microstacks.com

Open WebUI

A local AI workspace mapped to open-webui.microstacks.com. Map Traefik as the router, mount Open WebUI, import Ollama, then run a root-level model block that pulls the model through the linked Ollama service.

open-webui.microstacks
# Map Traefik as the router for the Open WebUI domain
$ stack map \
  --arguments=--providers.docker=true \
  --label 'traefik.http.routers.default.rule=PathPrefix(`/`)' \
  --label 'traefik.http.services.default.loadbalancer.server.url=http://127.0.0.1:80' \
  traefik:v3.4 open-webui.microstacks.com

# Mount Open WebUI at the root path
$ stack mount \
  --env OLLAMA_BASE_URL=http://127.0.0.1:11434 \
  ghcr.io/open-webui/open-webui:v0.6.25 \
  open-webui.microstacks.com/

# Import Ollama with its default server command
$ stack import \
  --env GODEBUG="tlsmlkem=0" \
  ollama/ollama:0.32.5 \
  open-webui.microstacks.com/ollama

# Add the qwen2.5-0.5b model job at the root path
$ stack import \
  --no-restart \
  --mask 11434/tcp \
  --require 127.0.0.1:11434 \
  --env GODEBUG="tlsmlkem=0" \
  ollama/ollama:0.32.5 \
  open-webui.microstacks.com/qwen2.5-0.5b -- \
  ollama pull qwen2.5:0.5b

# Link Ollama into the model address space
$ stack import \
  open-webui.microstacks.com/ollama \
  open-webui.microstacks.com/qwen2.5-0.5b/ollama

# Snap the Open WebUI stack
$ stack snap -r open-webui.microstacks.com

Redis Replica Set

A Redis replica set stack mapped to redis.rs.microstacks.com. Map Caddy as the router, mount RedisInsight, import Redis with instance-aware replica configuration, clone the Redis service block, and snap the primary plus replica vectors.

redis-replica-set.microstacks
# Map Caddy as the router for the Redis replica set domain
$ stack map caddy:2 redis.rs.microstacks.com -- \
  caddy reverse-proxy --from :80 --to 127.0.0.1:80

# Mount RedisInsight at the root path
$ stack mount \
  redis/redisinsight:3.8.0 \
  redis.rs.microstacks.com/

# Import Redis with instance-aware primary/replica configuration
$ stack import \
  --env 'N=${INSTANCE#1}' \
  redis:8.8.1 \
  redis.rs.microstacks.com/redis -- \
  redis-server \
    '${N:+--replicaof}' '${N:+127.0.0.1}' '${N:+6379}'

# Clone the Redis service block under itself
$ stack import \
  redis.rs.microstacks.com/redis \
  redis.rs.microstacks.com/redis/redis

# Snap RedisInsight and scale the Redis replica vectors
$ stack snap -r redis.rs.microstacks.com
$ stack scale local.redis.rs.microstacks.com/redis=3

Redis Cluster

A Redis cluster stack mapped to redis.cluster.microstacks.com. Map Caddy as the router, mount RedisInsight at the root path, import Redis with cluster ports, clone the Redis service block, and snap each vector into place.

redis.microstacks
# Map Caddy as the router for the Redis domain
$ stack map caddy:2 redis.cluster.microstacks.com -- \
  caddy reverse-proxy --from :80 --to 127.0.0.1:80

# Mount RedisInsight at the root path
$ stack mount \
  --env RI_REDIS_HOST=127.0.0.1 --env RI_REDIS_PORT=6379 \
  redis/redisinsight:3.8.0 \
  redis.cluster.microstacks.com/

# Import the first Redis cluster node
$ stack import \
  --endpoint 16379/tcp \
  redis:8.8.1 \
  redis.cluster.microstacks.com/redis -- \
  redis-server --cluster-enabled yes --appendonly yes --cluster-announce-ip \${BIND_ADDR}

# Clone the Redis service block under itself
$ stack import \
  redis.cluster.microstacks.com/redis \
  redis.cluster.microstacks.com/redis/redis

# Mount a config job to create the Redis cluster
$ stack mount \
  --no-restart \
  --require 127.0.0.{1..6}:6379 \
  redis:8.8.1 \
  redis.cluster.microstacks.com/config -- \
  redis-cli --cluster create 127.0.0.{1..6}:6379 --cluster-replicas 1 --cluster-yes

# Link Redis into the config address space
$ stack import \
  redis.cluster.microstacks.com/redis \
  redis.cluster.microstacks.com/config/redis

# Snap RedisInsight and scale the Redis cluster vectors
$ stack snap -r redis.cluster.microstacks.com
$ stack scale local.redis.cluster.microstacks.com/redis=6

MongoDB Replica Set

A MongoDB replica set stack mapped to mongo.rs.microstacks.com. Map Caddy as the router, mount Compass Web, import MongoDB with replica set mode, clone the Mongo service block, and initialize the replica set from a config job.

mongodb-replica-set.microstacks
# Map Caddy as the router for the MongoDB replica set domain
$ stack map caddy:2 mongo.rs.microstacks.com -- \
  caddy reverse-proxy --from :80 --to 127.0.0.1:80

# Mount Compass Web at the root path
$ stack mount \
  --require 127.0.0.1:27017 \
  --env 'CW_MONGO_URI=mongodb://1.localhost:27017,2.localhost:27017,3.localhost:27017/?replicaSet=rs0' \
  haohanyang/compass-web \
  mongo.rs.microstacks.com/

# Import MongoDB with replica set mode enabled
$ stack import \
  mongo:8.3.7 \
  mongo.rs.microstacks.com/mongo -- \
  mongod --replSet rs0 --bind_ip '${INSTANCE}.localhost'

# Clone the MongoDB service block under itself
$ stack import \
  mongo.rs.microstacks.com/mongo \
  mongo.rs.microstacks.com/mongo/mongo

# Run a config job to initialize the replica set
$ stack import \
  --no-restart \
  --require 127.0.0.{1..3}:27017 \
  alpine/mongosh:latest \
  mongo.rs.microstacks.com/config -- \
  mongosh --host 1.localhost --eval 'rs.initiate({_id:"rs0",members:[{_id:0,host:"1.localhost:27017"}]}); while (!db.hello().isWritablePrimary) { sleep(1000); }; rs.add("2.localhost:27017"); rs.add("3.localhost:27017"); rs.status()'

# Link MongoDB into the config address space
$ stack import \
  mongo.rs.microstacks.com/mongo \
  mongo.rs.microstacks.com/config/mongo

# Snap Compass Web and the MongoDB replica vectors
$ stack snap -r mongo.rs.microstacks.com
$ stack snap mongo.rs.microstacks.com/mongo
$ stack snap mongo.rs.microstacks.com/mongo

MongoDB Cluster

A sharded MongoDB cluster mapped to mongo.cluster.microstacks.com. Map Caddy as the router, mount Compass Web, define query, config, and shard blocks, wire their address spaces, and snap the cluster vectors.

mongodb-cluster.microstacks
# Map Caddy as the router for the MongoDB cluster domain
$ stack map caddy:2 mongo.cluster.microstacks.com -- \
  caddy reverse-proxy --from :80 --to 127.0.0.1:80

# Mount Compass Web at the root path
$ stack mount \
  --require 127.0.0.1:27017 \
  --env 'CW_MONGO_URI=mongodb://127.0.0.1:27017' \
  --http-port 8080 \
  haohanyang/compass-web \
  mongo.cluster.microstacks.com/ -- \
  compass-web --host 0.0.0.0

# Import the mongos query router
$ stack import \
  --require 127.0.0.{1..3}:27019 \
  mongo:8.3.7 \
  mongo.cluster.microstacks.com/query -- \
  mongos --configdb cfg/127.0.0.1:27019,127.0.0.2:27019,127.0.0.3:27019 --bind_ip '${INSTANCE}.microstacks'

# Import the config server replica set
$ stack import \
  --mask 27017/tcp \
  --endpoint 27019/tcp \
  mongo:8.3.7 \
  mongo.cluster.microstacks.com/query/config -- \
  mongod --configsvr --replSet cfg --bind_ip '${INSTANCE}.microstacks'

# Import shard0
$ stack import \
  --mask 27017/tcp \
  --endpoint 27018/tcp \
  mongo:8.3.7 \
  mongo.cluster.microstacks.com/query/shard0 -- \
  mongod --shardsvr --replSet shard0 --bind_ip '${INSTANCE}.microstacks'

# Import shard1
$ stack import \
  --mask 27017/tcp \
  --endpoint 27028/tcp \
  mongo:8.3.7 \
  mongo.cluster.microstacks.com/query/shard1 -- \
  mongod --shardsvr --replSet shard1 --bind_ip '${INSTANCE}.microstacks' --port 27028

# Initialize config and shard replica sets
$ stack import \
  --no-restart \
  --require 127.0.0.{1..3}:27019 \
  --require 127.0.0.{1..2}:27018 \
  --require 127.0.0.{1..2}:27028 \
  alpine/mongosh:latest \
  mongo.cluster.microstacks.com/init -- \
  mongosh --nodb --quiet --eval \
  'new Mongo("127.0.0.1:27019").getDB("admin").runCommand({replSetInitiate:{_id:"cfg",configsvr:true,members:[{_id:0,host:"127.0.0.1:27019"},{_id:1,host:"127.0.0.2:27019"},{_id:2,host:"127.0.0.3:27019"}]}});
   new Mongo("127.0.0.1:27018").getDB("admin").runCommand({replSetInitiate:{_id:"shard0",members:[{_id:0,host:"127.0.0.1:27018"},{_id:1,host:"127.0.0.2:27018"}]}});
   new Mongo("127.0.0.1:27028").getDB("admin").runCommand({replSetInitiate:{_id:"shard1",members:[{_id:0,host:"127.0.0.1:27028"},{_id:1,host:"127.0.0.2:27028"}]}});'

# Add shards through the query router
$ stack import \
  --no-restart \
  --require 127.0.0.1:27017 \
  --require 127.0.0.{1..2}:27018 \
  --require 127.0.0.{1..2}:27028 \
  alpine/mongosh:latest \
  mongo.cluster.microstacks.com/config -- \
  mongosh --host 127.0.0.1:27017 --quiet --eval \
  'db.adminCommand({addShard:"shard0/127.0.0.1:27018,127.0.0.2:27018"});
   db.adminCommand({addShard:"shard1/127.0.0.1:27028,127.0.0.2:27028"});
   sh.status();'

# Link query, config, shard, init, and config job address spaces
$ stack import mongo.cluster.microstacks.com/query \
  mongo.cluster.microstacks.com/query/query \
  mongo.cluster.microstacks.com/config/

$ stack import mongo.cluster.microstacks.com/query/config \
  mongo.cluster.microstacks.com/query/config/config \
  mongo.cluster.microstacks.com/{query/shard0,query/shard1,init}/

$ stack import mongo.cluster.microstacks.com/query/shard0 \
  mongo.cluster.microstacks.com/{init,config,query/config}/ \
  mongo.cluster.microstacks.com/query/shard0/shard0

$ stack import mongo.cluster.microstacks.com/query/shard1 \
  mongo.cluster.microstacks.com/{init,config,query/config}/ \
  mongo.cluster.microstacks.com/query/shard1/shard1

# Snap the MongoDB cluster vectors
$ stack snap -r mongo.cluster.microstacks.com
$ stack snap mongo.cluster.microstacks.com/query/config{,}
$ stack snap mongo.cluster.microstacks.com/query/shard{0,1}

Infrastructure as Code

The same model is available from code. You can define blocks, mount paths, import services, and snap vectors programmatically, then version and test those changes like the rest of your application.

stack/main.go
stack/main.go
package main

import (
    "github.com/microstacks/stack"
    "github.com/microstacks/stack/block"
    "github.com/microstacks/stack/vector"
)

func main() {
    hub, _ := stack.Hub("https://example.com")
    gw,  _ := hub.Gateway("example.com")
    root, _ := gw.Root()

    // Define a block — same fields as `stack import`.
    api := block.New("myorg/api:1.4",
        block.Kind(block.SERVICE),
        block.Env("DB_URL", "postgres://db/app"),
        block.Endpoint(8080, "tcp"),
    )

    // Mount at /api (like `stack mount`).
    root.Mount(api, "/api")

    // Place vectors close to users in two regions.
    api.Snap(vector.Node{Address: "ssh://ops@edge-fra1"})
    api.Snap(vector.Node{Address: "ssh://ops@edge-sin1"})
}
Free

self hosted

Run a single-node block stack and vector map together on infrastructure you manage.

Download

Deploy

$99/mo

Managed single-node block stack / 1-node vector map

Join waitlist

Single-node vector map

A managed single-node block stack connected to one vector map node in the cloud environment you choose.

Included features

Block stackSingle-node managed
Vector map1 node
CloudsAny cloud
StacksUnlimited
SupportCommunity

Snap

$299/mo

3-node HA quorum block stack / single-cloud vector map

Join waitlist

Single-cloud vector scaling

A three-node HA quorum block stack supporting a multi-node vector map inside one cloud environment.

Everything in Deploy, plus

Block stack3-node HA quorum
Vector mapMultiple nodes
CloudsSingle cloud
StacksUnlimited
SupportEmail, 1 business day

Scale

$499/mo

5-node fault-tolerant quorum block stack / multi-cloud vector map

Join waitlist

Federated multi-cloud vector map

A five-node fault-tolerant quorum block stack supporting vector maps distributed across multiple clouds.

Everything in Snap, plus

Block stack5-node fault-tolerant quorum
Vector mapMulti-cloud
CloudsMulti-cloud
StacksUnlimited
SupportPriority, 4 hour response
Enterprise pricingCustom plans for larger clusters, private deployments, and dedicated support.
Contact sales
